Mfr Part Number | TS5V330PWR |
Description | 5-V, 2:1 (SPDT), 4-channel video switch | PW | 16 | -40 to 85 |
Protocols | Composite,RGB |
Configuration | 2:1 SPDT |
Number of channels | 4.0 |
Bandwidth (MHz) | 300.0 |
Supply voltage (max) (V) | 5.5 |
Supply voltage (min) (V) | 4.0 |
Ron (typ) (mΩ) | 3000.0 |
Input/output voltage (min) (V) | 0.0 |
Input/output voltage (max) (V) | 5.5 |
Supply current (typ) (µA) | 3.0 |
ESD HBM (typ) (kV) | Standard |
Operating temperature range (°C) | -40 to 85 |
Package area (mm^2) | 32.0 |
Package size (L x W) (mm) | 5 x 6.4 |
Pin count | 16.0 |
Crosstalk (dB) | -63.0 |
ESD CDM (kV) | 1.0 |
Input/output continuous current (max) (mA) | 128.0 |
COFF (typ) (pF) | 4.0 |
CON (typ) (pF) | 14.0 |
Off isolation (typ) (dB) | -60.0 |
OFF-state leakage current (max) (µA) | 1.0 |
Propagation delay time (µs) | 0.006 |
Ron (max) (mΩ) | 10000.0 |
Ron channel match (max) (Ω) | Standard |
RON flatness (typ) (Ω) | Standard |
Turnoff time (disable) (max) (ns) | 6.0 |
Turnon time (enable) (max) (ns) | 6.0 |
VIH (min) (V) | 2.0 |
VIL (max) (V) | 0.8 |
